Custom U-Shaped Screw Conveyors Screw Feeders Shaftless Tubular Sludge, Cement, Dry Powder Carbon Steel & Stainless Steel Screw Conveyors Low-Cost Manufacturer Direct Supply

Custom U-Shaped Screw Conveyors Screw Feeders Shaftless Tubular Sludge, Cement, Dry Powder Carbon Steel & Stainless Steel Screw Conveyors Low-Cost Manufacturer Direct Supply

Marchio:	WeSeW
Numero di modello:	- Non lo so.
MOQ:	1 pz
prezzo:	US$10,000~US$20,000 per pc
Condizioni di pagamento:	T/T, Unione Occidentale
Capacità di approvvigionamento:	10000 set al mese

Informazione dettagliata

Descrizione del prodotto

Informazione dettagliata

Luogo di origine:

Cina

Certificazione:

CE,UL

Materiale:

Acciaio inossidabile

Funzione materiale:

Resistente al calore, resistente al fuoco

Applicazione:

Industria chimica, trasporto di cereali, trasporto minerario, centrale elettrica

Industrie applicabili:

Fabbrica di prodotti alimentari e bevande...

Rapporto di prova del macchinario:

Fornito

Utilizzo:

Trasportatore

Dimensione (L*W*H):

Personalizzato

Funzione:

Sistema di trasmissione

Caratteristica:

Alta efficienza

Velocità:

Ad alta velocità

Specifica:

Personalizzato

Dimensioni del pacchetto:

800.00cm * 50.00cm * 100.00cm

Peso lordo del pacco:

200.000kg

Struttura:

Sistema di trasporto

Imballaggi particolari:

cassa di legno

Capacità di alimentazione:

10000 set al mese

Evidenziare:

U-shaped screw conveyor for sludge

stainless steel shaftless screw feeder

low-cost carbon steel screw conveyor

Descrizione del prodotto

Custom U-Shaped Screw Conveyors & Screw Feeders

U-shaped screw conveyors utilize a helical screw within a U-shaped trough to efficiently transport bulk materials including powders, granules, and pellets. This innovative design offers superior sealing capabilities, simplified cleaning procedures, and easier maintenance access, making it particularly suitable for industries requiring strict dust control and hygiene standards such as chemical processing and food manufacturing.

Product Specifications

Material: Carbon Steel & Stainless Steel

Condition: New

Power: Custom Made

Dimensions: Custom Made

Voltage: 220/380V

Color: Customized Colors

Key Features & Benefits

U-shaped Trough Design: Provides higher capacity than traditional cylindrical screw conveyors and offers easier access for inspection and cleaning compared to sealed tube conveyors.
Superior Sealing: Enclosed design prevents dust leakage, making it ideal for dusty environments and applications where environmental contamination is a concern.
Easy Maintenance: Open-top design facilitates straightforward cleaning and inspection for blockages.
Material Compatibility: Handles a wide range of materials including powders, granules, and flakes across various industries.
Enhanced Rigidity: U-trough design provides increased structural stability to the conveyor system.

Industry Applications

Chemical Industry: Transporting plastic pellets and fertilizers
Food Processing: Conveying flour, sugar, and grains
Construction Materials: Handling cement and fly ash
Wastewater Treatment: Transporting dewatered sludge
Manufacturing Plants, Farms, Energy & Mining: Various bulk material handling applications

Design Considerations

Distance Limitations: Better suited for shorter transport distances compared to standard tubular screw conveyors
Material Sensitivity: May cause damage to fragile materials during conveyance

Product Gallery
